bolt |
O-ring |
Weight |
Order number* |
Working pressure (bar)CF |
|
|
2 pieces |
2 pieces |
|||||||||||||||
|
35 35 35 35 35 |
10L 12L 15L 16S 20S |
8 10 12 12 16 |
38 38 38 38 45 |
31.0 31.0 31.0 29.5 34.5 |
16.5 16.5 16.5 20.0 25.0 |
26.5 26.5 26.5 31.0 38.0 |
47.0 47.0 46.0 48.0 56.0 |
40 40 40 40 40 |
19 22 27 30 36 |
6.4 6.4 6.4 6.4 6.4 |
M6x22 M6x22 M6x22 M6x22 M6x22 |
M6x35 M6x35 M6x35 M6x40 M6x45 |
20x2.5 20x2.5 20x2.5 20x2.5 20x2.5 |
0.23 0.26 0.38 0.55 0.65 |
BFW10L/LK35 BFW12L/LK35 BFW15L/LK35 BFW16S/LK35 BFW20S/LK35 |
315 315 315 315 315 |
|
40 40 40 40 40 |
15L 18L 22L 28L 35L |
12 15 19 22 31 |
38 38 38 40 41 |
31.0 30.5 30.5 32.5 30.5 |
22.5 22.5 22.5 28.0 32.0 |
36.5 36.5 36.5 43.0 55.0 |
46.0 47.0 47.5 49.0 52.0 |
42 42 42 42 42 |
27 32 36 41 50 |
6.4 6.4 6.4 6.4 6.4 |
M6x22 M6x22 M6x22 M6x20 M6x22 |
M6x22 M6x22 M6x22 M6x50 M6x60 |
26x2.5 26x2.5 26x2.5 26x2.5 26x2.5 |
0.29 0.70 0.36 0.82 0.22 |
BFW15L/LK40 BFW18L/LK40 BFW22L/LK40 BFW28L/LK40 BFW35L/LK40 |
100 100 100 100 100 |
|
40 55 55 55 55 |
20S 35L 42L 20S 25S |
16 31 38 17 20 |
40 49 49 45 49 |
29.5 38.5 38.0 34.5 37.0 |
22.5 32.0 40.0 24.0 30.0 |
35.5 51.5 64.5 38.0 46.0 |
50.0 62.0 61.0 56.0 61.0 |
42 58 58 58 58 |
36 50 60 36 46 |
6.4 8.4 8.4 8.4 8.4 |
M6x22 M8x25 M8x25 M8x25 M8x25 |
M6x45 M8x60 M8x70 M8x50 M8x55 |
26x2.5 32x2.5 32x2.5 32x2.5 32x2.5 |
0.23 0.27 0.41 0.94 0.80 |
BFW20S/LK40 BFW35L/LK55 BFW42L/LK55 BFW20S/LK55 BFW25S/LK55 |
250 250 250 250 250 |
|
55 |
30S |
26 |
49 |
35.5 |
32.0 |
50.0 |
62.0 |
58 |
50 |
8.4 |
M8x25 |
M8x50 |
32x2.5 |
0.20 |
BFW30S/LK55 |
250 |
