THREAD |
DIME |
|||
|
E |
F |
A |
B |
S1 |
|
|
1BT9-02SPZ |
G1/8"X28 |
R1/8"X28 |
20 |
21 |
11 |
|
1BT9-02-04SPZ |
G1/8"X28 |
R1/4"X19 |
22.3 |
25.5 |
14 |
|
1BT9-04SPZ |
G1/4"X19 |
R1/4"X19 |
24.5 |
25.5 |
14 |
|
1BT9-04-02SPZ |
G1/4"X19 |
R1/8"X28 |
25 |
23.5 |
14 |
|
1BT9-04-06SPZ |
G1/4"X19 |
R3/8"X19 |
25 |
28.5 |
16 |
|
1BT9-04-08SPZ |
G1/4"X19 |
R1/2"X14 |
30 |
36 |
22 |
|
1BT9-06SPZ |
G3/8"X19 |
R3/8"X19 |
27.5 |
28.5 |
16 |
|
1BT9-06-04SPZ |
G3/8"X19 |
R1/4"X19 |
27.5 |
26.5 |
16 |
|
1BT9-06-08SPZ |
G3/8"X19 |
R1/2"X14 |
31 |
36 |
22 |
|
1BT9-08SPZ |
G1/2"X14 |
R1/2"X14 |
34.5 |
36 |
22 |
|
1BT9-08-04SPZ |
G1/2"X14 |
R1/4"X19 |
34 |
30.5 |
22 |
|
1BT9-08-06SPZ |
G1/2"X14 |
R3/8"X19 |
34.5 |
32.5 |
22 |
|
1BT9-08-12SPZ |
G1/2"X14 |
R3/4"X14 |
37.5 |
43.5 |
27 |
|
1BT9-08-16SPZ |
G1/2"X14 |
R1"X11 |
41 |
50 |
33 |
|
1BT9-10-08SPZ |
G5/8"X14 |
R1/2"X14 |
35 |
36 |
22 |
|
1BT9-10-12SPZ |
G5/8"X14 |
R3/4"X14 |
39 |
43.5 |
27 |
|
1BT9-12SPZ |
G3/4"X14 |
R3/4"X14 |
40 |
43.5 |
27 |
|
1BT9-12-06SPZ |
G3/4"X14 |
R3/8"X19 |
40 |
36 |
27 |
|
1BT9-12-08SPZ |
G3/4"X14 |
R1/2"X14 |
40 |
39.5 |
27 |
|
1BT9-12-16SPZ |
G3/4"X14 |
R1"X11 |
43.5 |
50 |
27 |
|
1BT9-12-20SPZ |
G3/4"X14 |
R1.1/4"X11 |
48 |
56.5 |
33 |
|
1BT9-16SPZ |
G1"X11 |
R1"X11 |
46 |
50 |
41 |
|
1BT9-16-08SPZ |
G1"X11 |
R1/2"X14 |
46 |
43 |
33 |
|
1BT9-16-12SPZ |
G1"X11 |
R3/4"X14 |
46 |
47.5 |
33 |
|
1BT9-16-20SPZ |
G1"X11 |
R1.1/4"X11 |
50.5 |
56.5 |
33 |
|
1BT9-20SPZ |
G1.1/4"X11 |
R1.1/4"X11 |
52 |
59 |
41 |
|
1BT9-20-12SPZ |
G1.1/4"X11 |
R3/4"X14 |
50.5 |
54 |
41 |
|
1BT9-20-16SPZ |
G1.1/4"X11 |
R1"X11 |
52 |
56.5 |
41 |
|
1BT9-20-24SPZ |
G1.1/4"X11 |
R1.1/2"X11 |
54.5 |
62.5 |
48 |
|
1BT9-24SPZ |
G1.1/2"X11 |
R1.1/2"X11 |
57.5 |
62 |
48 |
|
1BT9-24-20SPZ |
G1.1/2"X11 |
R1.1/4"X11 |
57.5 |
61 |
48 |
|
1BT9-24-32SPZ |
G1.1/2"X11 |
R2"X11 |
66 |
75 |
63 |
|
1BT9-32SPZ |
G2"X11 |
R2"X11 |
67 |
75 |
63 |
|
1BT9-32-24SPZ |
G2"X11 |
R1.1/2"X11 |
68 |
72 |
|
