PART NO.
|
THREAD
|
TUBE O.D.
|
DIMENSIONS
|
SEALING
|
||||
E
|
F
|
D1
|
l1
|
L1
|
S1
|
S2
|
RING DKI
|
|
7BC-04-12GDK/S
|
G1/4"X19
|
M12X1.5
|
6
|
14.5
|
35.5
|
19
|
14
|
DP-B04DK
|
7BC-04-14GDK/S
|
G1/4"X19
|
M14X1.5
|
8
|
14.5
|
35.5
|
19
|
17
|
DP-B04DK
|
7BC-04-16GDK/S
|
G1/4"X19
|
M16X1.5
|
10
|
14.5
|
36
|
19
|
19
|
DP-B04DK
|
7BC-04-18GDK/S
|
G1/4"X19
|
M18X1.5
|
12
|
14.5
|
36
|
19
|
22
|
DP-B04DK
|
7BD-04-14GDK/S
|
G1/4"X19
|
M14X1.5
|
6
|
14.5
|
35.5
|
19
|
17
|
DP-B04DK
|
7BD-04-16GDK/S
|
G1/4"X19
|
M16X1.5
|
8
|
14.5
|
35.5
|
19
|
19
|
DP-B04DK
|
7BD-04-18GDK/S
|
G1/4"X19
|
M18X1.5
|
10
|
14.5
|
36
|
19
|
22
|
DP-B04DK
|
7BD-04-20GDK/S
|
G1/4"X19
|
M20X1.5
|
12
|
14.5
|
39
|
19
|
24
|
DP-B04DK
|
7BD-08-14GDK/S
|
G1/2"X14
|
M14X1.5
|
6
|
20
|
42.5
|
27
|
17
|
DP-B08DK
|
7BD-08-16GDK/S
|
G1/2"X14
|
M16X1.5
|
8
|
20
|
43
|
27
|
19
|
DP-B08DK
|
7BD-08-18GDK/S
|
G1/2"X14
|
M18X1.5
|
10
|
20
|
43.5
|
27
|
22
|
DP-B08DK
|
7BD-08-20GDK/S
|
G1/2"X14
|
M20X1.5
|
12
|
20
|
45
|
27
|
24
|
DP-B08DK
|
