PART NO.
|
THREAD
|
TUBE O.D.
|
DIMENSIONS
|
MPa
|
||
|
E,F
|
D1,D2
|
L1
|
L2
|
S1,S2
|
||
|
3C-12
|
M12x1.5
|
6
|
33
|
32
|
14
|
31.5L
|
|
3C-14
|
M14x1.5
|
8
|
33
|
32
|
17
|
|
|
3C-16
|
M16x1.5
|
10
|
34
|
33
|
19
|
|
|
3C-18
|
M18x1.5
|
12
|
34
|
33
|
22
|
|
|
3C-22
|
M22x1.5
|
15
|
39
|
38
|
27
|
|
|
3C-26
|
M26x1.5
|
18
|
41
|
39
|
32
|
|
|
3C-30
|
M30x2
|
22
|
44
|
42
|
36
|
16L
|
|
3C-36
|
M36x2
|
28
|
48
|
46
|
46
|
|
|
3C-45
|
M45x2
|
35
|
52
|
48
|
50
|
|
|
3C-52
|
M52x2
|
42
|
57
|
52
|
60
|
|
|
3D-14
|
M14x1.5
|
6
|
33
|
32
|
17
|
63S
|
|
3D-16
|
M16x1.5
|
8
|
34
|
33
|
19
|
|
|
3D-18
|
M18x1.5
|
10
|
35
|
33
|
22
|
|
|
3D-20
|
M20x1.5
|
12
|
38
|
36
|
24
|
|
|
3D-22
|
M22x1.5
|
14
|
41
|
39
|
27
|
|
|
3D-24
|
M24x1.5
|
16
|
42
|
39
|
30
|
40S
|
|
3D-30
|
M30x2
|
20
|
48
|
44
|
36
|
|
|
3D-36
|
M36x2
|
25
|
53
|
46
|
46
|
|
|
3D-42
|
M42x2
|
30
|
62
|
52
|
50
|
|
|
3D-52
|
M52x2
|
38
|
67
|
52
|
60
|
31.5S
|
